XZCBD54W-1

SunLED
RoHS
RoHS RoHS compliant
Package 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description LED BLUE CLEAR 0805 SMD
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.3784
≥1 USD $0.3784
≥10 USD $0.24992
≥100 USD $0.166584
≥500 USD $0.115192
≥1000 USD $0.09599
Inventory: 1192
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric)
Shape RECTANGULAR

Technical

Packaging Cut Tape (CT)
Published 2014
Size / Dimension 2.00mm Lx1.25mm W
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Color Blue
Packing Method TR, 7 INCH
Number of Functions 1
Terminal Pitch 2.35mm
Case Code (Metric) 2012
Case Code (Imperial) 0805
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 3.3V
Viewing Angle 120°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.20mmx1.25mm
Luminous Intensity 98 mcd
Lens Transparency Clear
Wavelength - Peak 460nm
Lens Color Colorless
Forward Current-Max 0.03A
Wavelength - Dominant 465nm

Dimensions

Height 750μm

Compliance

RoHS Status ROHS3 Compliant
