VRPG3312X
RoHS
RoHS compliant
RoHS compliantPackage Radial - 3 Leads
Category Optoelectronics / LED Indication - Discrete
Description
Red/Green 3 mm 59/67° 8/12 mcd White Diffused 2/2.1 V Round LED Through Hole
PDF
/
Inventory: 3925
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height (Max) 6.00mm
Technical
T-code T-1
Wavelength - Dominant 567nm Green 624nm Red
Overall Height 4.8mm
Reverse Voltage 4V
Lens Color White
Wavelength - Peak 560nm Green 630nm Red
Lens Transparency Diffused
Millicandela Rating 12mcd Green, 8mcd Red
Luminous Intensity 8.0/12.0 mcd
Lens Size 3.10mm Dia
Lens Style Round with Domed Top
Current - Test 20mA Green 20mA Red
Forward Current 30mA
Optoelectronic Device Type DUAL COLOR LED
Viewing Angle 68°, 59°
Voltage - Forward (Vf) (Typ) 2.1V Green 2V Red
Power Dissipation 75mW
Configuration Common Cathode
Number of Elements 2
Depth 3.8mm
Number of Functions 1
Max Power Dissipation 75mW
Subcategory Visible LEDs
Color Green, Red
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Size / Dimension 3.10mm Dia
Series 3312X
Packaging Bulk
Physical
Number of Pins 3
Package / Case Radial - 3 Leads
Mounting Type Through Hole
Mount Through Hole
