PY1113F-TR
RoHS
/
Package 2-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description
1112C Series 2.1 x 1.0 x 0.6 mm 25 mA 147° Green Color SMT LED With White Lens
PDF
/
Buying Options
Total Price: USD $0.04
Unit Price: USD $0.04085
≥1 USD $0.04085
≥10 USD $0.03325
≥100 USD $0.0323
≥500 USD $0.03135
≥1000 USD $0.0304
Inventory: 12806
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status Non-RoHS Compliant
Dimensions
Height 1mm
Technical
Wavelength - Dominant 572nm
Reverse Voltage 4V
Lens Color White
Wavelength - Peak 570nm
Lens Transparency Diffused
Luminous Intensity 11.7 mcd
Lens Size 1.70mmx0.60mm
Lens Style Rectangle with Domed Top
Current - Test 20mA
Forward Current 25mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 150°, 147°
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 70mW
Configuration Standard
Number of Elements 1
Reach Compliance Code unknown
Depth 1.7mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
Color Green
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Obsolete
Pbfree Code yes
Size / Dimension 2.10mm Lx1.00mm W
Series 1113F
Published 2010
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 2-SMD, No Lead
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
