MU13-9102
RoHS
/
Package 8-DIP Module
Category Optoelectronics / LED Indication - Discrete
Description
LED Bi-Color Red/Yellow Green 660nm/570nm 8-Pin Bag
PDF
/
Inventory: 2170
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP Module
Number of Pins 8
Technical
Packaging Tube
Published 2013
Size / Dimension 10.10mm Lx10.10mm W
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 8
Color Green, Red
Packing Method BULK
Number of Functions 1
Terminal Pitch 2.54mm
Reach Compliance Code unknown
Operating Temperature (Min) -40°C
Configuration Common Anode
Voltage - Forward (Vf) (Typ) 2.1V Green 1.7V Red
Optoelectronic Device Type DUAL COLOR LED
Current - Test 20mA Green 20mA Red
Lens Style Square with Flat Top
Lens Size 9.00mm
Luminous Intensity 12 mcd
Millicandela Rating 40mcd Green, 12mcd Red
Lens Transparency Diffused
Wavelength - Peak 570nm Green 660nm Red
Lens Color White
Forward Current-Max 0.03A
Dimensions
Height 9mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
