HPY1105W-TR

Stanley Electric Co
RoHS
RoHS RoHS compliant
Package 1206 (3216 Metric)
Category Optoelectronics / LED Indication - Discrete
Description Yellow/Green 1206 40° 50 mcd Water Clear 2.1 V Dome Lens LED Surface Mount
PDF
/
Buying Options
Total Price: USD $0.08
Unit Price: USD $0.08075
≥1 USD $0.08075
≥10 USD $0.0665
≥100 USD $0.0646
≥500 USD $0.0627
≥1000 USD $0.05985
Inventory: 1325
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Height 1.85mm

Technical

Wavelength - Dominant 572nm
Reverse Voltage 4V
Lens Color Colorless
Wavelength - Peak 570nm
Lens Transparency Clear
Luminous Intensity 50 mcd
Lens Size 1.60mm Dia
Lens Style Round with Domed Top
Current - Test 20mA
Forward Current 30mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 40°
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 75W
Configuration Standard
Number of Elements 1
Case Code (Imperial) 1206
Case Code (Metric) 3216
Depth 1.6mm
Terminal Pitch 3.3mm
Number of Functions 1
Packing Method TAPE AND REEL
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 3.20mm Lx1.60mm W
Series 1105W
Published 2010
Packaging Tape & Reel (TR)

Physical

Number of Pins 2
Package / Case 1206 (3216 Metric)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 11 Weeks
