BR1111C-TR image
Favorite
BR1111C-TR image
Favorite
RoHS
RoHS RoHS compliant
Package 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description Red 0603 136/141° 11.7 mcd White Diffused LED Surface Mount
PDF
/
Buying Options
Total Price: USD $42.75
Unit Price: USD $0.4275
≥100 USD $0.4275
≥500 USD $0.41325
≥1000 USD $0.39995
Inventory: 3460
Minimum: 100
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Height 700μm

Technical

Wavelength - Dominant 647nm
Reverse Voltage 4V
Lens Color White
Wavelength - Peak 660nm
Lens Transparency Diffused
Luminous Intensity 11.7 mcd
Lens Size 1.10mmx0.80mm
Lens Style Rectangle with Flat Top
Current - Test 20mA
Forward Current 25mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 136°, 141°
Voltage - Forward (Vf) (Typ) 1.7V
Power Dissipation 57.5mW
Configuration Standard
Number of Elements 1
Case Code (Imperial) 0603
Case Code (Metric) 1608
Depth 800μm
Number of Functions 1
Packing Method TAPE AND REEL
Color Red
Min Operating Temperature -30°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 1.60mm Lx0.80mm W
Series 1111C
Published 2010
Packaging Tape & Reel (TR)

Physical

Shape Rectangular
Number of Pins 2
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 11 Weeks
