BG1111C-TR
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN DIFFUSED 1608 SMD
PDF
/
Buying Options
Total Price: USD $8.82
Unit Price: USD $8.81885
≥1 USD $8.81885
≥10 USD $7.23615
≥100 USD $7.01005
≥500 USD $6.78395
≥1000 USD $6.55785
Inventory: 1004
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Number of Pins 2
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2001
Series 1111C
Size / Dimension 1.60mm Lx0.80mm W
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Number of Terminations 2
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Color Green
Packing Method TAPE AND REEL
Number of Functions 1
Depth 800μm
Case Code (Metric) 1608
Case Code (Imperial) 0603
Number of Elements 1
Configuration Standard
Power Dissipation 70mW
Voltage - Forward (Vf) (Typ) 2.1V
Viewing Angle 153°, 146°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 25mA
Current - Test 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.10mmx0.80mm
Luminous Intensity 2.4 mcd
Lens Transparency Diffused
Wavelength - Peak 555nm
Lens Color White
Reverse Voltage 4V
Wavelength - Dominant 558nm
Dimensions
Height 700μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
