AYPG1211F-TR
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description
Yellow 2 mm 150/140° 3 mcd White Diffused 2.2 V Right Angle LED Surface Mount
PDF
/
Buying Options
Total Price: USD $0.57
Unit Price: USD $0.572
≥1 USD $0.572
≥10 USD $0.352
≥100 USD $0.2024
≥500 USD $0.158382
Inventory: 13354
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height 1.15mm
Technical
Wavelength - Dominant 567nm Green 590nm Yellow
Reverse Voltage 4V
Lens Color White
Wavelength - Peak 560nm Green 580nm Yellow
Lens Transparency Diffused
Millicandela Rating 5.2mcd Green, 3mcd Yellow
Luminous Intensity 3 mcd
Lens Size 2.00mmx1.00mm
Lens Style Rectangle with Domed Top
Current - Test 20mA Green 20mA Yellow
Forward Current 25mA
Optoelectronic Device Type DUAL COLOR LED
Viewing Angle 150°, 140° Green, 150°, 140° Yellow
Voltage - Forward (Vf) (Typ) 2.1V Green 2.2V Yellow
Power Dissipation 70mW
Current 25A
Voltage 2V
Configuration Common Anode
Number of Elements 2
Depth 2mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
Color Green, Yellow
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Active
Size / Dimension 3.00mm Lx2.00mm W
Series 1211F
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 3
Package / Case 2-SMD, No Lead
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
