GM1WA55311A
RoHS
/
Package 0606 (1616 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED RGB 1616 SMD
PDF
/
Inventory: 6872
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height 600μm
Technical
Wavelength - Dominant 616nm Red 527nm Green 473nm Blue
Reverse Voltage 5V
Millicandela Rating 20mcd Red, 70mcd Green, 23mcd Blue
Luminous Intensity 23 mcd
Lens Size 1.00mmx1.60mm
Lens Style Rectangle with Flat Top
Current - Test 5mA Red 5mA Green 5mA Blue
Forward Current 10mA
Optoelectronic Device Type TRIPLE COLOR LED
Voltage - Forward (Vf) (Typ) 1.9V Red 3V Green 2.9V Blue
Power Dissipation 45.5mW
Configuration Common Anode
Number of Elements 3
Case Code (Imperial) 0606
Case Code (Metric) 1616
Depth 1.6mm
Number of Functions 1
Packing Method TAPE AND REEL
Color Red, Green, Blue (RGB)
Min Operating Temperature -20°C
Max Operating Temperature 80°C
Terminal Finish GOLD
Number of Terminations 4
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Discontinued
JESD-609 Code e4
Size / Dimension 1.60mm Lx1.60mm W
Packaging Cut Tape (CT)
Physical
Shape RECTANGULAR
Number of Pins 4
Package / Case 0606 (1616 Metric)
Mounting Type Surface Mount
Mount Surface Mount
