GM1HD55200A image
Favorite
GM1HD55200A image
Favorite
RoHS
/
Package 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description LED RED CLEAR 1608 SMD
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.26885
≥1 USD $0.26885
≥10 USD $0.2204
≥100 USD $0.21375
≥500 USD $0.2071
≥1000 USD $0.20045
Inventory: 7809
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Height 650μm

Technical

Peak Wavelength 635 nm
Wavelength - Dominant 635nm
Reverse Voltage 5V
Lens Color Colorless
Lens Transparency Clear
Luminous Intensity 12.5 mcd
Lens Size 1.20mmx0.80mm
Lens Style Rectangle
Current - Test 20mA
Forward Current 30mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 160°
Voltage - Forward (Vf) (Typ) 2.0V
Power Dissipation 84mW
Configuration SINGLE
Number of Elements 1
Depth 1.6mm
Number of Functions 1
Packing Method BULK
Color Red
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Discontinued
Size / Dimension 1.60mm Lx0.80mm W
Packaging Cut Tape (CT)

Physical

Shape RECTANGULAR
Number of Pins 2
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount
