GM5SAE35P0A
RoHS
/
Package 2-PLCC
Category Optoelectronics / LED Indication - Discrete
Description
LED WARM WHITE 3500K 2PLCC
PDF
/
Inventory: 1898
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2-PLCC
Number of Pins 2
Technical
Packaging Tape & Reel (TR)
Published 2009
Size / Dimension 3.20mm Lx2.80mm W
Part Status Obsolete
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Max Operating Temperature 100°C
Min Operating Temperature -30°C
Color White, Warm
Max Power Dissipation 123mW
Depth 2.8mm
Number of Elements 1
Configuration Standard
Power Dissipation 111mW
Voltage - Forward (Vf) (Typ) 3.2V
Viewing Angle 120 °
Forward Current 30mA
Current - Test 20mA
Lens Style Round with Flat Top
Lens Size 2.40mm Dia
Forward Voltage 3.2V
Luminous Intensity 2.1 cd
Millicandela Rating 2100mcd
Luminous Flux 5 lm
Wavelength - Dominant 3500K
Color Rendering Index (CRI) 83
Dimensions
Height 1.9mm
Length 3.2mm
Width 2.8mm
Height (Max) 1.90mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
