GM5SAE30P0A
RoHS
/
Package 2-PLCC
Category Optoelectronics / LED Indication - Discrete
Description
SHARP GM5SAE30P0A LED, Warm White, SMD, 30 mA, 3.2 V, 2 cd
PDF
/
Inventory: 6399
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Height 1.9mm
Technical
Color Rendering Index (CRI) 85
Wavelength - Dominant 3000K
Luminous Flux 5 lm
Millicandela Rating 2050mcd
Luminous Intensity 2.05 cd
Lens Size 2.40mm Dia
Lens Style Round with Flat Top
Current - Test 20mA
Forward Current 30mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 120 °
Voltage - Forward (Vf) (Typ) 3.2V
Power Dissipation 111mW
Configuration Standard
Number of Elements 1
Depth 2.8mm
Terminal Pitch 3mm
Number of Functions 1
Max Power Dissipation 123mW
Packing Method TAPE AND REEL
Color White, Warm
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Obsolete
Size / Dimension 3.20mm Lx2.80mm W
Published 2009
Packaging Tape & Reel (TR)
Physical
Number of Pins 2
Package / Case 2-PLCC
Mounting Type Surface Mount
Mount Surface Mount
