GM5SAE27P0A
RoHS
/
Package 2-PLCC
Category Optoelectronics / LED Indication - Discrete
Description
LED WARM WHITE 2700K 2PLCC
PDF
/
Inventory: 4088
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 2-PLCC
Number of Pins 2
Technical
Packaging Tape & Reel (TR)
Size / Dimension 3.20mm Lx2.80mm W
Part Status Obsolete
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Number of Terminations 2
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Color White, Warm
Power Rating 123mW
Packing Method TAPE AND REEL
Max Power Dissipation 123mW
Number of Functions 1
Terminal Pitch 3mm
Depth 2.8mm
Number of Elements 1
Configuration Standard
Power Dissipation 111mW
Voltage - Forward (Vf) (Typ) 3.2V
Viewing Angle 120 °
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 30mA
Current - Test 20mA
Lens Style Round with Flat Top
Lens Size 2.40mm Dia
Luminous Intensity 2 cd
Millicandela Rating 2000mcd
Illumination Color White
Luminous Flux 4.9 lm
Wavelength - Dominant 2700K
Color Rendering Index (CRI) 85
Dimensions
Height 1.9mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
