GM4WA25300A
RoHS
/
Package 8-SMD
Category Optoelectronics / LED Indication - Discrete
Description
LED RGB 8SMD
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8056
≥1 USD $0.8056
≥10 USD $0.6612
≥100 USD $0.6403
≥500 USD $0.62035
≥1000 USD $0.59945
Inventory: 11186
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SMD
Number of Pins 8
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2012
Size / Dimension 5.00mm Lx2.50mm W
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Number of Terminations 8
Terminal Finish SILVER
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Color Red, Green, Blue (RGB)
Packing Method TAPE AND REEL
Number of Functions 1
Depth 2.5mm
Reach Compliance Code unknown
Number of Elements 3
Configuration Independent
Power Dissipation 300mW
Voltage - Forward (Vf) (Typ) 2.3V Red 3.3V Green 3.3V Blue
Viewing Angle 110 °
Optoelectronic Device Type TRIPLE COLOR LED
Forward Current 30mA
Current - Test 21mA Red 25mA Green 7mA Blue
Lens Style Rectangle with Flat Top
Luminous Intensity 2 cd
Reverse Voltage 5V
Dimensions
Height 2.5mm
Compliance
RoHS Status RoHS Compliant
