GM1WA55321A image
Favorite
GM1WA55321A image
Favorite
RoHS
/
Package 0606 (1616 Metric)
Category Optoelectronics / LED Indication - Discrete
Description LED RGB 0606 SMD
PDF
/
Inventory: 4206
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0606 (1616 Metric)

Technical

Packaging Tape & Reel (TR)
Published 2009
Size / Dimension 1.60mm Lx1.60mm W
Part Status Obsolete
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Color Red, Green, Blue (RGB)
Depth 1.6mm
Case Code (Metric) 1616
Case Code (Imperial) 0606
Number of Elements 3
Voltage - Forward (Vf) (Typ) 2V Red 3V Green 2.9V Blue
Viewing Angle 110°
Forward Current 10mA
Current - Test 5mA Red 5mA Green 5mA Blue
Lens Style Rectangle with Flat Top
Lens Size 1.20mmx1.60mm
Luminous Intensity 25 mcd
Millicandela Rating 28mcd Red, 75mcd Green, 25mcd Blue

Compliance

RoHS Status RoHS Compliant
