GM1HY55200A
RoHS
/
Package 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED YELLOW CLEAR 1608 SMD
PDF
/
Inventory: 7009
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Number of Pins 2
Supplier Device Package 1608
Technical
Packaging Tape & Reel (TR)
Published 2002
Size / Dimension 1.60mm Lx0.80mm W
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Color Yellow
Depth 1.6mm
Number of Elements 1
Configuration Standard
Power Dissipation 84mW
Voltage - Forward (Vf) (Typ) 2.1V
Forward Current 30mA
Current - Test 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.00mmx0.80mm
Forward Voltage 2.1V
Luminous Intensity 11.5 mcd
Millicandela Rating 11.5mcd
Illumination Color Yellow
Lens Transparency Clear
Wavelength - Peak 585nm
Lens Color Colorless
Reverse Voltage 5V
Dimensions
Height 600μm
Length 1.6mm
Width 800μm
Height (Max) 0.60mm
Compliance
RoHS Status RoHS Compliant
