C8WT728
RoHS
/
Package 6-SMD, J-Lead
Category Optoelectronics / LED Indication - Discrete
Description
PLCC6, WARM WHITE TOP LED, NO BIN
PDF
/
Inventory: 3090
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD, J-Lead
Number of Pins 6
Technical
Packaging Digi-Reel?
Published 2009
Size / Dimension 5.00mm Lx5.00mm W
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 6
Terminal Finish SILVER
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color White, Neutral
Power Rating 324mW
Packing Method TAPE AND REEL 7"
Max Power Dissipation 324mW
Number of Functions 1
Terminal Pitch 5mm
Configuration Standard
Power Dissipation 324mW
Voltage - Forward (Vf) (Typ) 3.3V
Viewing Angle 120°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 60mA
Current - Test 3 x 20mA
Lens Style Round with Flat Top
Lens Size 4.00mm Dia
Luminous Intensity 5 cd
Millicandela Rating 5000mcd
Illumination Color White
Luminous Flux 16.5 lm
Reverse Voltage 5V
Wavelength - Dominant 4800K
Number of LEDs 1
Color Rendering Index (CRI) 83
Dimensions
Height 1.4mm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
