SMLF13WBDW1
RoHS
RoHS compliant
RoHS compliantPackage 0704 (1810 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED WHITE 1810 SMD R/A
PDF
/
Inventory: 2887
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 400μm
Technical
Reverse Voltage-Max 5V
Millicandela Rating 90mcd
Luminous Intensity 90 mcd
Lens Size 1.40mmx0.35mm
Lens Style Rectangle with Flat Top
Forward Current 5mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 180 °
Voltage - Forward (Vf) (Typ) 2.9V
Configuration Standard
Base Part Number SML-F13
Terminal Pitch 2.1mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Color White
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Number of Terminations 2
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Size / Dimension 1.80mm Lx1.00mm W
Published 2007
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Package / Case 0704 (1810 Metric)
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
