SMLD12WBN1W1
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED INDICATION SMD
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.3256
≥1 USD $0.3256
≥10 USD $0.29128
≥100 USD $0.16764
≥500 USD $0.13119
Inventory: 43482
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 0.65mm
Technical
Overall Height 0.55mm
Forward Current-Max 0.02A
Millicandela Rating 120mcd
Luminous Intensity 120.0 mcd
Lens Size 1.20mmx0.80mm
Lens Style Rectangle with Flat Top
Current - Test 5mA
Optoelectronic Device Type SINGLE COLOR LED
Voltage - Forward (Vf) (Typ) 2.9V
Configuration SINGLE
Operating Temperature (Min) -40°C
Operating Temperature (Max) 100°C
Terminal Pitch 1.65mm
Number of Functions 1
Packing Method TR, 7 INCH
Color White
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 1.60mm Lx0.80mm W
Series SMLD12x
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Surface Mount YES
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
