SML-E12UWT86

ROHM Semiconductor
RoHS
RoHS RoHS compliant
Package 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description LED RED DIFFUSED 0603 SMD
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.3784
≥1 USD $0.3784
≥10 USD $0.23144
≥100 USD $0.13288
≥500 USD $0.10399
≥1000 USD $0.095322
Inventory: 1434
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height 460μm

Technical

Reverse Voltage-Max 4V
Number of LEDs 1
Wavelength 624 nm
Lens Color White
Lens Transparency Diffused
Millicandela Rating 100mcd
Luminous Intensity 85 mcd
Lens Size 1.20mmx0.80mm
Lens Style Rectangle with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 140 °
Voltage - Forward (Vf) (Typ) 2.1V
Configuration Standard
Case Code (Imperial) 0603
Case Code (Metric) 1608
Base Part Number SML-E12
Number of Functions 1
Packing Method TAPE AND REEL 7"
Subcategory Visible LEDs
Color Red
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Size / Dimension 1.60mm Lx0.80mm W
Series EXCELED?
Published 2007
Packaging Tape & Reel (TR)

Physical

Shape RECTANGULAR
Number of Pins 2
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 10 Weeks
