SML-E12DWT86
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED ORANGE DIFFUSED 0603 SMD
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.3784
≥1 USD $0.3784
≥10 USD $0.23144
≥100 USD $0.13288
≥500 USD $0.10399
≥1000 USD $0.095322
Inventory: 1480
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Number of Pins 2
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2007
Series EXCELED?
Size / Dimension 1.60mm Lx0.80mm W
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 2
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Color Orange
Subcategory Visible LEDs
Packing Method TAPE AND REEL 7"
Number of Functions 1
Base Part Number SML-E12
Case Code (Metric) 1608
Case Code (Imperial) 0603
Configuration Standard
Voltage - Forward (Vf) (Typ) 1.9V
Viewing Angle 140 °
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.20mmx0.80mm
Luminous Intensity 200 mcd
Millicandela Rating 200mcd
Lens Transparency Diffused
Lens Color White
Wavelength - Dominant 606nm
Number of LEDs 1
Reverse Voltage-Max 4V
Dimensions
Height 360μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
