SML-A12D8TT86
RoHS
RoHS compliant
RoHS compliantPackage 2-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description
LED ORANGE CLEAR 1611 SMD R/A
PDF
/
Buying Options
Total Price: USD $0.43
Unit Price: USD $0.4312
≥1 USD $0.4312
≥10 USD $0.26312
≥100 USD $0.151272
≥500 USD $0.118386
Inventory: 1523
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Package / Case 2-SMD, No Lead
Number of Pins 2
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2015
Series EXCELED?
Size / Dimension 1.60mm Lx1.15mm W
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Orange
Subcategory Visible LEDs
Packing Method TAPE AND REEL 7"
Number of Functions 1
Base Part Number SML-A12
Case Code (Metric) 1613
Case Code (Imperial) 0605
Configuration Standard
Voltage - Forward (Vf) (Typ) 2.2V
Viewing Angle 130 °
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.20mmx0.55mm
Luminous Intensity 100 mcd
Millicandela Rating 100mcd
Lens Transparency Clear
Lens Color Colorless
Wavelength - Dominant 605nm
Number of LEDs 1
Reverse Voltage-Max 5V
Dimensions
Height 550μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
