SML-512DWT86
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED ORANGE DIFFUSED 0603 SMD
PDF
/
Buying Options
Total Price: USD $0.45
Unit Price: USD $0.4488
≥1 USD $0.4488
≥10 USD $0.29744
≥100 USD $0.196856
≥500 USD $0.151967
Inventory: 1117
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Number of Pins 2
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2006
Size / Dimension 1.60mm Lx0.80mm W
JESD-609 Code e4
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Orange
Subcategory Visible LEDs
Power Rating 75mW
Packing Method TAPE AND REEL
Number of Functions 1
Base Part Number SML-512
Case Code (Metric) 1608
Case Code (Imperial) 0603
Configuration Standard
Voltage - Forward (Vf) (Typ) 2V
Viewing Angle 140 °
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.20mmx0.80mm
Luminous Intensity 100 mcd
Millicandela Rating 100mcd
Lens Transparency Diffused
Lens Color White
Wavelength 611 nm
Wavelength - Dominant 606nm
Number of LEDs 1
Reverse Voltage-Max 5V
Dimensions
Height 650μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
