SML-511WWT86
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED YELLOW DIFFUSED 0603 SMD
PDF
/
Buying Options
Total Price: USD $0.43
Unit Price: USD $0.4312
≥1 USD $0.4312
≥10 USD $0.26664
≥100 USD $0.153296
≥500 USD $0.119988
Inventory: 3613
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 650μm
Technical
Reverse Voltage-Max 4V
Number of LEDs 1
Wavelength 590 nm
Lens Color White
Lens Transparency Diffused
Millicandela Rating 40mcd
Luminous Intensity 40 mcd
Lens Size 1.20mmx0.80mm
Lens Style Rectangle with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 140 °
Voltage - Forward (Vf) (Typ) 2V
Configuration Standard
Case Code (Imperial) 0603
Case Code (Metric) 1608
Base Part Number SML-511
Number of Functions 1
Packing Method TAPE AND REEL
Power Rating 62mW
Subcategory Visible LEDs
Color Yellow
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e4
Size / Dimension 1.60mm Lx0.80mm W
Published 2006
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount
