SML-020MVTT86
RoHS
RoHS compliant
RoHS compliantPackage 1210 (3225 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN/RED CLEAR 1210 SMD
PDF
/
Buying Options
Total Price: USD $0.66
Unit Price: USD $0.66
≥1 USD $0.66
≥10 USD $0.42768
≥100 USD $0.280368
≥500 USD $0.221311
Inventory: 1852
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1210 (3225 Metric)
Number of Pins 4
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2003
Series SML-020
Size / Dimension 3.00mm Lx2.50mm W
JESD-609 Code e4
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Number of Terminations 4
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Green, Red
Number of Functions 1
Base Part Number SML-02
Case Code (Metric) 3225
Case Code (Imperial) 1210
Configuration Independent
Voltage - Forward (Vf) (Typ) 2.2V Green 2V Red
Viewing Angle 100 °
Optoelectronic Device Type DUAL COLOR LED
Forward Current 20mA
Current - Test 20mA Green 20mA Red
Lens Style Rectangle with Flat Top
Lens Size 2.30mmx2.10mm
Luminous Intensity 6.3 mcd
Millicandela Rating 20mcd Green, 6.3mcd Red
Illumination Color Green, Red
Lens Transparency Clear
Wavelength - Peak 570nm Green 650nm Red
Lens Color Colorless
Number of LEDs 2
Dimensions
Height 1.5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
