SML-020MLTT86
RoHS
RoHS compliant
RoHS compliantPackage 1210 (3225 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN/RED CLEAR 1210 SMD
PDF
/
Buying Options
Total Price: USD $0.63
Unit Price: USD $0.6336
≥1 USD $0.6336
≥10 USD $0.41536
≥100 USD $0.27192
≥500 USD $0.21465
Inventory: 66
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 1.5mm
Technical
Reverse Voltage-Max 4V
Number of LEDs 2
Lens Color Colorless
Wavelength - Peak 570nm Green 660nm Red
Lens Transparency Clear
Illumination Color Green, Red
Millicandela Rating 20mcd Green, 16mcd Red
Luminous Intensity 16 mcd
Lens Size 2.30mmx2.10mm
Lens Style Rectangle with Flat Top
Current - Test 20mA Green 20mA Red
Forward Current 20mA
Optoelectronic Device Type DUAL COLOR LED
Viewing Angle 100 °
Voltage - Forward (Vf) (Typ) 2.2V Green 1.75V Red
Configuration Independent
Case Code (Imperial) 1210
Case Code (Metric) 3225
Base Part Number SML-02
Number of Functions 2
Packing Method TAPE AND REEL
Power Rating 60mW
Subcategory Visible LEDs
Color Green, Red
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Number of Terminations 4
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e4
Size / Dimension 3.00mm Lx2.50mm W
Series SML-020
Published 2003
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 4
Package / Case 1210 (3225 Metric)
Mounting Type Surface Mount
Mount Surface Mount
