SLA-360MT3F
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN CLEAR T-1 T/H
PDF
/
Inventory: 1949
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 5.2mm
Diameter 3.1mm
Technical
Reverse Voltage-Max 4V
T-code T-1
Number of LEDs 1
Wavelength - Dominant 570nm
Forward Voltage-Max 3V
Wavelength 563 nm
Lens Color Colorless
Lens Transparency Clear
Luminous Intensity 100 mcd
Lens Size 3mm T-1
Lens Style Round with Domed Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 40°
Voltage - Forward (Vf) (Typ) 2.3V
Configuration Standard
Operating Temperature (Max) 85°C
Base Part Number SLA-360
Number of Functions 1
Subcategory Visible LEDs
Additional Feature HIGH RELIABILITY
Color Green
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Last Time Buy
Pbfree Code yes
JESD-609 Code e1
Published 2007
Packaging Bulk
Physical
Number of Pins 2
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
