LNJ418Q8YRA
RoHS
/
Package 1206 (3216 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED AMBER DOME LENS SMD
PDF
/
Inventory: 6828
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height 1.1mm
Diameter 1.42mm
Technical
Forward Current-Max 0.02A
Wavelength - Peak 590nm
Luminous Intensity 7 mcd
Lens Size 1.42mm Dia
Lens Style Round with Domed Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 30 °
Voltage - Forward (Vf) (Typ) 2V
Configuration Standard
Operating Temperature (Max) 85°C
Case Code (Imperial) 1206
Case Code (Metric) 3216
Base Part Number LNJ*18
Reach Compliance Code unknown
Number of Functions 1
Packing Method BULK
HTS Code 8541.40.20.00
Color Amber
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
Size / Dimension 3.20mm Lx1.60mm W
Published 2001
Packaging Tape & Reel (TR)
Physical
Package / Case 1206 (3216 Metric)
Mounting Type Surface Mount
Mount Surface Mount
