LNJ218C82RA image
Favorite
LNJ218C82RA image
Favorite
RoHS
/
Package 1206 (3216 Metric)
Category Optoelectronics / LED Indication - Discrete
Description LED RED SMD
PDF
/
Inventory: 9605
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1206 (3216 Metric)

Technical

Packaging Tape & Reel (TR)
Published 2001
Size / Dimension 3.20mm Lx1.60mm W
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Color Red
Base Part Number LNJ*18
Case Code (Metric) 3216
Case Code (Imperial) 1206
Configuration Standard
Voltage - Forward (Vf) (Typ) 1.92V
Viewing Angle 30 °
Current - Test 10mA
Lens Style Round with Flat Top
Lens Size 1.70mm Dia
Forward Voltage 1.92V
Luminous Intensity 75 mcd
Millicandela Rating 75mcd
Wavelength - Peak 645nm
Wavelength 645 nm

Dimensions

Diameter 1.42mm
Height 1.6mm
Length 3.2mm
Width 1.6mm
Height (Max) 1.60mm

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
