LN260RPX image
Favorite
RoHS
/
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description Standard LEDs - Through Hole LED RED DIFFUSED 2x3MM RECT
PDF
/
Inventory: 5617
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Height 4mm

Technical

Dominant Wavelength 700 nm
Reverse Voltage-Max 4V
Number of LEDs 1
Millicandela Rating 0.7mcd
Luminous Intensity 700 μcd
Lens Size 3.00mmx2.00mm
Lens Style Rectangle with Flat Top
Current - Test 20mA
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Voltage - Forward (Vf) (Typ) 2.2V
Configuration Standard
Base Part Number LN*60
Reach Compliance Code unknown
Number of Functions 1
Subcategory Visible LEDs
Color Red
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Published 2008
Packaging Bulk

Physical

Shape RECTANGULAR
Number of Pins 2
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 14 Weeks
