SML-LXL1206SRC-TR
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED RED CLEAR 1206 SMD
PDF
/
Buying Options
Total Price: USD $0.32
Unit Price: USD $0.3168
≥1 USD $0.3168
≥10 USD $0.19272
≥100 USD $0.110616
≥500 USD $0.086601
Inventory: 1222
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Height 1.5mm
Technical
Lens Color Colorless
Wavelength - Peak 660nm
Lens Transparency Clear
Millicandela Rating 90mcd
Luminous Intensity 90 mcd
Lens Size 1.10mm Dia
Lens Style Round with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 20°
Voltage - Forward (Vf) (Typ) 1.7V
Configuration Standard
Case Code (Imperial) 1206
Case Code (Metric) 3216
Terminal Pitch 3mm
Number of Functions 1
Packing Method TAPE AND REEL
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 3.00mm Lx1.50mm W
Published 2005
Packaging Tape & Reel (TR)
Physical
Number of Pins 2
Package / Case 1206 (3216 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
