SML-LXFT1206SUGCTR
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
Standard LEDs - SMD 3.2x1.6mm SMT LED Green 574nm Wtr Clr
PDF
/
Inventory: 6225
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1206 (3216 Metric)
Number of Pins 2
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2007
Size / Dimension 3.20mm Lx1.60mm W
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 4 (72 Hours)
Number of Terminations 2
Terminal Finish NOT SPECIFIED
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Color Green
Subcategory Visible LEDs
Packing Method TAPE AND REEL
Number of Functions 1
Terminal Pitch 3.75mm
Configuration Independent
Voltage - Forward (Vf) (Typ) 2.2V
Viewing Angle 140°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Rectangle with Flat Top
Lens Size 2.00mmx1.60mm
Luminous Intensity 45.0 mcd
Millicandela Rating 45mcd
Lens Transparency Clear
Wavelength - Peak 574nm
Lens Color Colorless
Overall Height 0.75mm
Number of LEDs 1
Dimensions
Height (Max) 1.60mm
Compliance
RoHS Status ROHS3 Compliant
