LTW-008ZDL
RoHS
/
Package 2-SMD, J-Lead
Category Optoelectronics / LED Indication - Discrete
Description
LED WHITE SMD R/A
PDF
/
Buying Options
Total Price: USD $0.1
Unit Price: USD $0.1026
≥1 USD $0.1026
≥10 USD $0.08455
≥100 USD $0.0817
≥500 USD $0.07885
≥1000 USD $0.076
Inventory: 14004
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Height 800μm
Technical
Reverse Voltage 5V
Lens Color Yellow
Millicandela Rating 1300mcd
Luminous Intensity 1.3 cd
Lens Style Rectangle with Flat Top
Current - Test 20mA
Forward Current 30mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 115°
Voltage - Forward (Vf) (Typ) 3.3V
Power Dissipation 120mW
Configuration Standard
Number of Elements 1
Depth 1.2mm
Number of Functions 1
Packing Method TAPE AND REEL 7"
Additional Feature IC COMPATIBLE
Color White
Min Operating Temperature -30°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 2.80mm Lx1.20mm W
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Number of Pins 2
Package / Case 2-SMD, J-Lead
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
