LTL-3223A
RoHS
/
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description
LED RED DIFFUSED T/H
PDF
/
Inventory: 6351
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Shape RECTANGULAR
Technical
Packaging Bulk
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 100°C
Min Operating Temperature -55°C
Color Red
Additional Feature IC COMPATIBLE, HIGH RELIABILITY
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Number of Functions 1
Terminal Pitch 2.54mm
Reach Compliance Code unknown
Configuration Standard
Voltage - Forward (Vf) (Typ) 2V
Viewing Angle 130°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Flat Top
Lens Size 7.10mmx2.40mm
Luminous Intensity 6.3 mcd
Millicandela Rating 6.3mcd
Lens Transparency Diffused
Wavelength - Peak 635nm
Forward Voltage-Max 2.8V
Wavelength - Dominant 623nm
Dimensions
Height 7.7mm
Compliance
RoHS Status RoHS Compliant
