LTJ-811HR
RoHS
RoHS compliant
RoHS compliantPackage 12-DIP (0.600, 15.24mm)
Category Optoelectronics / LED Indication - Discrete
Description
LED RED DIFFUSED T/H
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 12-DIP (0.600, 15.24mm)
Number of Pins 12
Technical
Packaging Tube
Published 2001
JESD-609 Code e0
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 12
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 85°C
Min Operating Temperature -35°C
Color Red
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Packing Method BULK
Max Power Dissipation 75mW
Number of Functions 1
Terminal Pitch 2.54mm
Depth 22.6mm
Number of Elements 6
Configuration Standard
Power Dissipation 75mW
Voltage - Forward (Vf) (Typ) 2.1V
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 25mA
Current - Test 20mA
Lens Style Round with Domed Top
Lens Size 20.00mm Dia
Luminous Intensity 25 mcd
Lens Transparency Diffused
Wavelength - Peak 635nm
Reverse Voltage 5V
Forward Voltage-Max 2.8V
Wavelength - Dominant 623nm
Dimensions
Diameter 23mm
Height 13.5mm
Length 22.6mm
Width 22.6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
