WP7113SRD/D
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Optoelectronics / LED Indication - Discrete
Description
Red T-1 3/4 5 mm 30° Tinted Diffused 600 mcd 1.85 V Solid State LED Through Hole
PDF
/
Buying Options
Total Price: USD $0.66
Unit Price: USD $0.655587
≥1 USD $0.655587
≥10 USD $0.618485
≥100 USD $0.583474
≥500 USD $0.550443
≥1000 USD $0.519294
Inventory: 6104
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Weight 346.544571mg
Technical
Packaging Bulk
Published 2007
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Additional Feature HIGH RELIABILITY
HTS Code 8541.40.20.00
Packing Method TAPE AND REEL
Number of Functions 1
Terminal Pitch 2.54mm
Configuration Standard
Interface UART
Max Supply Voltage 3.6V
Min Supply Voltage 1.71V
Voltage - Forward (Vf) (Typ) 1.85V
Viewing Angle 30°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Round with Domed Top
Lens Size 5mm T-1 3/4
Luminous Intensity 210 mcd
Lens Transparency Diffused
Wavelength - Peak 655nm
Forward Current-Max 0.03A
Wavelength - Dominant 640nm
Dimensions
Height 8.6mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
