WP59EYC
RoHS
RoHS compliant
RoHS compliantPackage Radial - 3 Leads
Category Optoelectronics / LED Indication - Discrete
Description
LED RED/YELLOW CLEAR T-1 3/4 T/H
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.3784
≥1 USD $0.3784
≥10 USD $0.23496
≥100 USD $0.134904
≥500 USD $0.105591
≥1000 USD $0.087991
≥3000 USD $0.082122
Inventory: 1086
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 8.6mm
Technical
Wavelength - Dominant 617nm Red 588nm Yellow
Lens Color Colorless
Wavelength - Peak 627nm Red 590nm Yellow
Lens Transparency Clear
Illumination Color Red, Yellow
Millicandela Rating 100mcd Red, 80mcd Yellow
Luminous Intensity 60 mcd
Lens Size 5mm T-1 3/4
Lens Style Round with Domed Top
Current - Test 20mA Red 20mA Yellow
Forward Current 20mA
Optoelectronic Device Type DUAL COLOR LED
Viewing Angle 24°
Voltage - Forward (Vf) (Typ) 2V Red 2.1V Yellow
Configuration Common Cathode
Terminal Pitch 2.54mm
Number of Functions 1
HTS Code 8541.40.20.00
Additional Feature IC COMPATIBLE, HIGH RELIABILITY
Color Red, Yellow
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2010
Packaging Bulk
Physical
Package / Case Radial - 3 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 12 Weeks
