WP1503YD

Kingbright
RoHS
RoHS RoHS compliant
Package Radial
Category Optoelectronics / LED Indication - Discrete
Description LED YELLOW DIFFUSED T-1 3/4 T/H
PDF
/
Buying Options
Total Price: USD $0.19
Unit Price: USD $0.1936
≥1 USD $0.1936
≥10 USD $0.15488
≥100 USD $0.069784
≥500 USD $0.06299
≥1000 USD $0.051744
≥3000 USD $0.045003
Inventory: 1663
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case Radial

Technical

Packaging Bulk
Published 2011
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Color Yellow
HTS Code 8541.40.20.00
Number of Functions 1
Terminal Pitch 2.54mm
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Configuration Standard
Voltage - Forward (Vf) (Typ) 2.1V
Viewing Angle 60°
Optoelectronic Device Type SINGLE COLOR LED
Current - Test 20mA
Lens Style Round with Domed Top
Lens Size 5mm T-1 3/4
Luminous Intensity 30 mcd
Lens Transparency Diffused
Wavelength - Peak 590nm
Forward Current-Max 0.03A
Wavelength - Dominant 588nm

Dimensions

Height 8.6mm

Compliance

RoHS Status ROHS3 Compliant
