APTR3216CGCK
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN CLEAR CHIP SMD
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.3256
≥1 USD $0.3256
≥10 USD $0.25784
≥100 USD $0.11572
≥500 USD $0.104526
≥1000 USD $0.085862
Inventory: 84792
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount, Bottom Entry
Package / Case 1206 (3216 Metric)
Number of Pins 2
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2009
Series Heli-R
Size / Dimension 3.20mm Lx1.60mm W
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Green
Packing Method TAPE AND REEL
Number of Functions 1
Terminal Pitch 3.6mm
Case Code (Metric) 3216
Case Code (Imperial) 1206
Configuration Standard
Voltage - Forward (Vf) (Typ) 2.1V
Viewing Angle 120°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.40mmx1.60mm
Luminous Intensity 40 mcd
Millicandela Rating 50mcd
Lens Transparency Clear
Wavelength - Peak 574nm
Lens Color Colorless
Wavelength - Dominant 570nm
Number of LEDs 1
Dimensions
Height 1.05mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
