APTD3216EC
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
Round with Domed Top 1 SINGLE COLOR LED Red LED Indication Discrete 5V 20mA 50mcd 35°
PDF
/
Buying Options
Total Price: USD $0.36
Unit Price: USD $0.3608
≥1 USD $0.3608
≥10 USD $0.24024
≥100 USD $0.160336
≥500 USD $0.110915
≥1000 USD $0.092435
Inventory: 10683
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 1.8mm
Technical
Reverse Voltage-Max 5V
Number of LEDs 1
Wavelength - Dominant 617nm
Lens Color Colorless
Wavelength - Peak 627nm
Lens Transparency Clear
Millicandela Rating 50mcd
Luminous Intensity 50 mcd
Lens Size 1.60mm Dia
Lens Style Round with Domed Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 35°
Voltage - Forward (Vf) (Typ) 2V
Configuration Standard
Case Code (Imperial) 1206
Case Code (Metric) 3216
Terminal Pitch 3.75mm
Number of Functions 1
Packing Method TAPE AND REEL
Subcategory Visible LEDs
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 3.20mm Lx1.60mm W
Published 2009
Packaging Tape & Reel (TR)
Physical
Number of Pins 2
Package / Case 1206 (3216 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
