APTD1608SEC/J3

Kingbright
RoHS
RoHS RoHS compliant
Package 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description LED RED CLEAR CHIP SMD
PDF
/
Buying Options
Total Price: USD $0.64
Unit Price: USD $0.6424
≥1 USD $0.6424
≥10 USD $0.41976
≥100 USD $0.275264
≥500 USD $0.217307
Inventory: 1353
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Height 950μm

Technical

Number of LEDs 1
Wavelength - Dominant 625nm
Lens Color Colorless
Wavelength - Peak 640nm
Lens Transparency Clear
Millicandela Rating 900mcd
Luminous Intensity 900 mcd
Lens Size 0.70mm Dia
Lens Style Round with Domed Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 60°
Voltage - Forward (Vf) (Typ) 2.2V
Configuration Standard
Case Code (Imperial) 0603
Case Code (Metric) 1608
Number of Functions 1
Packing Method TAPE AND REEL 7"
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 1.60mm Lx0.80mm W
Published 2010
Packaging Digi-Reel?

Physical

Number of Pins 4
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
