APT3216MGC
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED 3.2X1.6MM 570NM GRN CLR SMD
PDF
/
Buying Options
Total Price: USD $0.57
Unit Price: USD $0.572
≥1 USD $0.572
≥10 USD $0.37576
≥100 USD $0.248424
≥500 USD $0.191805
Inventory: 6787
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 750μm
Technical
Reverse Voltage-Max 5V
Wavelength - Dominant 570nm
Forward Voltage-Max 2.5V
Lens Color Colorless
Wavelength - Peak 574nm
Lens Transparency Clear
Millicandela Rating 70mcd
Luminous Intensity 70 mcd
Lens Size 2.00mmx1.60mm
Lens Style Rectangle with Flat Top
Forward Current 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 2.1V
Configuration Standard
Case Code (Imperial) 1206
Case Code (Metric) 3216
Terminal Pitch 3.75mm
Number of Functions 1
Packing Method TAPE AND REEL
Subcategory Visible LEDs
HTS Code 8541.40.20.00
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 85°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 3.20mm Lx1.60mm W
Published 2011
Packaging Tape & Reel (TR)
Physical
Shape RECTANGULAR
Package / Case 1206 (3216 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
