APT2012SGC
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN CLEAR CHIP SMD
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.2552
≥1 USD $0.2552
≥10 USD $0.2024
≥100 USD $0.090904
≥500 USD $0.082122
≥1000 USD $0.067461
Inventory: 34812
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric)
Number of Pins 2
Supplier Device Package Chip LED
Technical
Packaging Tape & Reel (TR)
Published 2009
Size / Dimension 2.00mm Lx1.25mm W
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Green
Capacitance 15pF
Power Rating 62.5mW
Case Code (Metric) 2012
Case Code (Imperial) 0805
Configuration Standard
Voltage - Forward (Vf) (Typ) 2.2V
Viewing Angle 120°
Forward Current 20mA
Current - Test 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.30mmx1.25mm
Forward Voltage 2.2V
Luminous Intensity 15 mcd
Millicandela Rating 12mcd
Illumination Color Green
Lens Transparency Clear
Wavelength - Peak 565nm
Lens Color Colorless
Wavelength 568 nm
Wavelength - Dominant 568nm
Number of LEDs 1
Dimensions
Height 750μm
Length 2mm
Width 1.25mm
Height (Max) 0.75mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
