APT2012SECK/J4-PRV

Kingbright
RoHS
RoHS RoHS compliant
Package 0805 (2012 Metric)
Category Optoelectronics / LED Indication - Discrete
Description Standard LEDs - SMD SMD CHIP LED LAMP 2.0x1.25mm ORANGE
PDF
/
Buying Options
Total Price: USD $0.53
Unit Price: USD $0.528
≥1 USD $0.528
≥10 USD $0.32384
≥100 USD $0.186032
≥500 USD $0.145587
Inventory: 1526
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric)
Shape RECTANGULAR

Technical

Packaging Cut Tape (CT)
Published 2013
Size / Dimension 2.00mm Lx1.25mm W
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Orange
Packing Method TR, 7 INCH
Number of Functions 1
Terminal Pitch 2.35mm
Case Code (Metric) 2012
Case Code (Imperial) 0805
Configuration Standard
Voltage - Forward (Vf) (Typ) 2.2V
Viewing Angle 120°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.30mmx1.25mm
Luminous Intensity 550 mcd
Millicandela Rating 550mcd
Lens Transparency Clear
Wavelength - Peak 611nm
Lens Color Colorless
Wavelength - Dominant 605nm

Dimensions

Height 750μm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
