APT1608CGCK
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN CLEAR CHIP SMD
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.264
≥1 USD $0.264
≥10 USD $0.20856
≥100 USD $0.09372
≥500 USD $0.084621
≥1000 USD $0.069502
Inventory: 195913
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Number of Pins 2
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2010
Size / Dimension 1.60mm Lx0.80mm W
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Gold (Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Green
Subcategory Visible LEDs
Power Rating 75mW
Packing Method TAPE AND REEL
Number of Functions 1
Case Code (Metric) 1608
Case Code (Imperial) 0603
Configuration Standard
Voltage 3V
Current 3A
Power Dissipation 75mW
Voltage - Forward (Vf) (Typ) 2.1V
Viewing Angle 120°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Flat Top
Lens Size 1.20mmx0.80mm
Luminous Intensity 50 mcd
Millicandela Rating 50mcd
Lens Transparency Clear
Wavelength - Peak 574nm
Lens Color Colorless
Reverse Voltage 5V
Wavelength - Dominant 570nm
Number of LEDs 1
Max Junction Temperature (Tj) 115°C
Dimensions
Height 850μm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
