APHHS1005QBC/D
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1005 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED BLUE CLEAR CHIP SMD
PDF
/
Buying Options
Total Price: USD $0.45
Unit Price: USD $0.4488
≥1 USD $0.4488
≥10 USD $0.2772
≥100 USD $0.159456
≥500 USD $0.124784
Inventory: 29841
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0402 (1005 Metric)
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2009
Size / Dimension 1.00mm Lx0.50mm W
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Blue
HTS Code 8541.40.20.00
Subcategory Visible LEDs
Power Rating 120mW
Packing Method TAPE AND REEL 7"
Number of Functions 1
Terminal Pitch 1.1mm
Case Code (Metric) 1005
Case Code (Imperial) 0402
Configuration Standard
Voltage - Forward (Vf) (Typ) 3.3V
Viewing Angle 140°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Rectangle with Flat Top
Lens Size 0.80mmx0.50mm
Luminous Intensity 60 mcd
Millicandela Rating 60mcd
Lens Transparency Clear
Wavelength - Peak 460nm
Lens Color Colorless
Forward Voltage-Max 4V
Wavelength - Dominant 465nm
Reverse Voltage-Max 5V
Dimensions
Height 600μm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
