APHHS1005LSECK/J4-PF

Kingbright
RoHS
RoHS RoHS compliant
Package 0402 (1005 Metric)
Category Optoelectronics / LED Indication - Discrete
Description LED ORANGE CLEAR 2SMD
PDF
/
Buying Options
Total Price: USD $0.46
Unit Price: USD $0.4576
≥1 USD $0.4576
≥10 USD $0.30008
≥100 USD $0.198704
≥500 USD $0.153446
Inventory: 1092
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height (Max) 0.60mm

Technical

Wavelength - Dominant 605nm
Overall Height 0.5mm
Forward Current-Max 0.03A
Lens Color Colorless
Wavelength - Peak 611nm
Lens Transparency Clear
Millicandela Rating 100mcd
Luminous Intensity 100.0 mcd
Lens Size 0.80mmx0.50mm
Lens Style Rectangle with Flat Top
Current - Test 2mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 1.8V
Configuration Independent
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Terminal Pitch 0.9mm
Number of Functions 1
Packing Method TR, 7 INCH
Color Orange
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Size / Dimension 1.00mm Lx0.50mm W
Published 2017
Packaging Tape & Reel (TR)

Physical

Shape RECTANGULAR
Surface Mount YES
Package / Case 0402 (1005 Metric)
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
