APG1005CGC-T
RoHS
RoHS compliant
RoHS compliantPackage 0402 (1005 Metric)
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN CLEAR CHIP SMD
PDF
/
Buying Options
Total Price: USD $1.31
Unit Price: USD $1.31005
≥1 USD $1.31005
≥10 USD $1.0754
≥100 USD $1.0412
≥500 USD $1.00795
≥1000 USD $0.9747
Inventory: 1100
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 250μm
Technical
Wavelength - Dominant 571nm
Forward Current-Max 0.025A
Lens Color Colorless
Wavelength - Peak 572nm
Lens Transparency Clear
Luminous Intensity 35 mcd
Lens Size 0.60mmx0.50mm
Lens Style Rectangle with Flat Top
Current - Test 20mA
Optoelectronic Device Type SINGLE COLOR LED
Viewing Angle 120°
Voltage - Forward (Vf) (Typ) 2V
Configuration Standard
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Case Code (Imperial) 0402
Case Code (Metric) 1005
Terminal Pitch 0.9mm
Number of Functions 1
Packing Method TR, 7 INCH
Color Green
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Size / Dimension 1.00mm Lx0.50mm W
Published 2013
Packaging Cut Tape (CT)
Physical
Shape RECTANGULAR
Package / Case 0402 (1005 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
