APDA3020SECK/J3-PF

Kingbright
RoHS
RoHS RoHS compliant
Package 2-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description LED RED CLEAR 2SMD R/A
PDF
/
Buying Options
Total Price: USD $0.53
Unit Price: USD $0.528
≥1 USD $0.528
≥10 USD $0.32384
≥100 USD $0.186032
≥500 USD $0.145587
Inventory: 5359
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Package / Case 2-SMD, No Lead
Manufacturer Package Identifier APDA3020SECK/J3-PF

Technical

Packaging Cut Tape (CT)
Published 2014
Size / Dimension 3.00mm Lx2.80mm W
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 2
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
HTS Code 8541.40.20.00
Packing Method TAPE AND REEL 7"
Number of Functions 1
Terminal Pitch 3mm
Configuration Standard
Power Dissipation 84mW
Voltage - Forward (Vf) (Typ) 2.2V
Viewing Angle 10°
Optoelectronic Device Type SINGLE COLOR LED
Forward Current 20mA
Lens Style Round with Domed Top
Lens Size 1.90mm Dia
Luminous Intensity 3.8 cd
Millicandela Rating 3800mcd
Lens Transparency Clear
Wavelength - Peak 640nm
Lens Color Colorless
Reverse Voltage 5V
Wavelength - Dominant 625nm
T-code T-3/4
Max Junction Temperature (Tj) 115°C

Dimensions

Height 2.2mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
