APBL3025ESGC-F01
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category Optoelectronics / LED Indication - Discrete
Description
LED GREEN/RED CLEAR 1208 SMD
PDF
/
Buying Options
Total Price: USD $0.39
Unit Price: USD $0.3872
≥1 USD $0.3872
≥10 USD $0.2376
≥100 USD $0.136488
≥500 USD $0.106841
Inventory: 130213
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 4-SMD, No Lead
Number of Pins 4
Shape RECTANGULAR
Technical
Packaging Tape & Reel (TR)
Published 2009
Size / Dimension 3.00mm Lx2.50mm W
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 4
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Green, Red
Packing Method TAPE AND REEL
Number of Functions 1
Terminal Pitch 2.7mm
Case Code (Metric) 3020
Case Code (Imperial) 1208
Configuration Independent
Voltage - Forward (Vf) (Typ) 2.2V Green 2V Red
Viewing Angle 100°
Optoelectronic Device Type DUAL COLOR LED
Forward Current 20mA
Current - Test 20mA Green 20mA Red
Lens Style Rectangle with Flat Top
Lens Size 2.00mmx2.50mm
Luminous Intensity 20 mcd
Millicandela Rating 20mcd Green, 15mcd Red
Illumination Color Green, Red
Lens Transparency Clear
Wavelength - Peak 565nm Green 627nm Red
Lens Color Colorless
Wavelength - Dominant 568nm Green 617nm Red
Dimensions
Height 1.4mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
